Quaife QBE46Z Ford Focus Mk3 ST250 (2WD) & RS (4WD) 5-Speed Sequential Gearbox
QBE46Z is a five-speed sequential conversion gearbox for the Ford ST250 2WD and Ford Focus RS Mk3 4WD gearboxes. QBE46Z features a replacement Quaife outer gearbox maincase, which houses five straight-cut, close-ratio gears, and a compact, drum style sequential gearchange mechanism. This combines with an open face dog design to ensure a rapid, positive sequential gear shift.
Careful design by Quaife allows the QBE46Z to retain the original bellhousing, plus the stock Ford clutch, differential, driveshafts and mounting points. This enables easy installation of the QBE46Z sequential gearbox into the ST250 and RS.
Key features of the QBE46Z include:
āĀ Complete, built sequential conversion gearbox, compatible with both ST250 2WD and RS 4WD gearboxes
āĀ Gearkit reuses original bellhousing from donor gearbox
āĀ Drum style shift mechanism for fast, reliable gear changes
āĀ Retains OEM clutch, differential, driveshafts and mounts
āĀ Optional Quaife ATBĀ® differential
āĀ Strengthened outer casing
āĀ 5 wider than standard gears for additional strength
āĀ New generation of gearchange mechanism allows fitment into front or rear wheel drive configurations
āĀ Compatible with flatshift systems
āĀ Includes oil temprature sensor
āĀ Supplied with either a manual lever and cable or air actuator for paddleshift
Gear Ratios:
1stĀ Ā Ā 2ndĀ Ā Ā 3rdĀ Ā Ā 4thĀ Ā Ā Ā 5th
2.769Ā 1.882Ā Ā 1,381Ā Ā 1.043Ā Ā 0.821Ā Straight Cut
3.200Ā 1.864Ā Ā 1.423Ā Ā 1.172Ā Ā 1.032Ā Helical
Final Drive Ratios:
3.471Ā Ā 3.938Ā Straight Cut
3.545Ā Ā 3.810Ā Helical
Quaife QKE38Z Ford IB5 5-Speed Sequential Gearkit
Fordās IB5 gearbox has been mated to a wide range of vehicles over the years, including versions of both the Mk1 & Mk2 Focus, various Mk4 to Mk6 Fiestas, the Puma, the Mk1 Ka and the Mk6 Escort.
The Quaife QKE38Z 5-speed sequential gearkit retains the stock IB5 clutch, differential, driveshafts and mounts for a simple and affordable assembly. Designed to dramatically improve the levels of performance available thanks to its quick-shifting properties, QKE38Z is an ideal product for motorsport and fast road applications.
Key features include:
- Five straight-cut, close-ratio gears with motorsport suited final drive ratios.
- Ultra fast sequential gearshift with drum style change mechanism.
- Open face dog design ensuring positive sequential shift.
- Retains stock Ford IB5 clutch, diff, driveshafts and mounts.
- Optional LED digital gear position indicator.
- Optional heavy duty input shaft for high horse power.
- Optional Quaife ATBĀ® Differential
- Includes a new transmission housing, sequential gear lever and cable.
- Uses standard Ford IB5 bellhousing, (not supplied).
Gear ratios:
1st Ā Ā Ā 2nd Ā Ā Ā 3rd Ā Ā Ā 4th Ā Ā Ā 5th
2.583Ā Ā 1.867Ā Ā 1.421Ā Ā 1.130 Ā 1.042
gjrgbn jrfnbjfn45jfnjfnfjnjnh0.960
Final drive ratios:
3.857 Ā 4.083 Ā 4.380 Ā 4.545Ā 4.690 Ā 4.910 Ā 5.080
Quaife QKE45Z Ford/Volvo M66 5-Speed Sequential Gearkit
Quaife are excited to announce the launch of QKE45Z, our 5-speed sequential gearkit suitable for Fordās M66 gearbox.
This transmission is fitted predominantly to the Mk2 Focus, and weāre expecting a high take-up from owners of ST and RS derivatives of Fordās second generation hatchback.
Itās also worth noting that the M66 gearbox, (as with many components made during the period of Fordās Premier Automotive Group), was fitted to a number of Volvo models too, expanding the scope of QKE45Z even further. Applicable Volvos will include, but are not limited to, both FWD and AWD iterations of C30, S40, V50, S60, C70 and V70, (for those keen on recreating a more up-to-date version of the 850 used in the BTCC).
Key features include:
- Suitable for Ford Focus Mk2 and both FWD & AWD Volvo models fitted with the M66 gearbox
- Gearkit retains original bellhousing from gearbox
- Optional Quaife ATBĀ® (except Focus RS) Differential
- Strengthened outer casing
- Drum style shift mechanism for fast reliable gear changes
- Choice of straight cut or helical gears
- Retains OEM clutch, differential, driveshafts and mounts
- 5 wider than standard gears for additional strength
- New generation of gearchange mechanism allows fitment into front or rear wheel drive configurations
Gear ratios:
1stĀ Ā Ā Ā Ā Ā 2ndĀ Ā Ā Ā Ā 3rdĀ Ā Ā Ā 4thĀ Ā Ā Ā Ā 5th
2.833Ā Ā Ā 2.067Ā Ā Ā 1.556Ā Ā Ā 1.263Ā Ā Ā 1.087Ā Ā Straight cut
2.867Ā Ā Ā 1.900Ā Ā Ā 1.400Ā Ā Ā 1.107Ā Ā Ā 0.935Ā Ā Helical
Final drive:
3.500Ā Ā 3.941Ā Ā Straight cut
3.909Ā Ā Ā Ā Ā Ā Ā Ā Ā Helical
